TQ3403-R

Wi-Fi 6E (802.11ax) Wireless Access

Allied Telesis TQ3403-R features a 3-radio design supporting 2.4GHz, 5GHz, and 6GHz, and a raw capacity of up to 2.4 Gigabits – and it runs the Enterprise-class AlliedWare Plus operating system. Enable a superior user experience with the performance of Wi-Fi 6E, and automated wireless network optimization.

Add to quoteView Datasheet

Key Features

Auto-detection and connection of client devices using Passpoint® and OpenRoaming
Automated backup, plug-and-play recovery, and zero-touch network roll-outs with the Autonomous Management Framework Plus (AMF Plus)
Automatically optimized wireless coverage and connectivity for a superior user experience with Autonomous Wave Control (AWC)
Centralized management and monitoring of larger Wi-Fi networks with AWC in Vista Manager
Consistent administration across the network using the same Enterprise-class AlliedWare Plus operating system as Allied Telesis switches, firewalls, and routers
Easy user access management with Captive Portal
Flexible backbone connectivity with the Multi-Gigabit (1/2.5G) uplink port
High-value Wi-Fi 6E AP supporting crowded wireless environments with a 3-radio design, efficient bandwidth distribution, and consistent connectivity and throughput
Simplified management of smaller Wi-Fi networks with the wireless controller built-in to the Device GUI
Visibility of application usage from the wireless edge using Deep Packet Inspection (DPI), with time-based statistics and graphs for proactive monitoring in Vista Manager

Specifications

Physical

Product	Width x Depth x Height		Weight	100M/1G/2.5G (RJ-45)Copper Ports
TQ3403-R	200 x 210 x 47 mm (7.87 x 8.23 x 1.85 in)	2 x 2 (2.4GHz) + 2 x 2 (5GHz) + 2 x 2 (6GHz)	1.17 kg (2.43 lb)	1 (PoE-in port)

Power Characteristics

Product	Power Supply	Average Power Consumption	Maximum Power Consumption	Max Heat Dissipation
TQ3403-R	100-240VAC	15W	20W	61.4 BTU/h
	PoE	14W	24W	66.15 BTU/h

Ordering Information

AT-TQ3403-R-xx

Enterprise-Class Wi-Fi 6E Wireless AP Router
with 3 wireless radios (2×2 2.4GHZ and 2×2 5GHz and 2×2 6GHz),
and embedded antenna

Where xx =

05 Regulatory Domain: Other countries⁽¹⁾

02 Regulatory Domain: Taiwan

⁽¹⁾ Please check the Compliance section on page 2 of the datasheet to see which countries are certified to use these access points

AT-PWRADP-01

AC adapter

AT-6101GP-yy

Gigabit Ethernet PoE+ (802.3at) injector

AT-7101GHTm-yy

Multi-Gigabit Ethernet PoE++ (802.3bt) injector

AT-BRKT-CONV-AP1

Replacement bracket converter

Where yy =

10 for US power cord

30 for UK power cord

40 for Australian power cord

50 for European power cord

Wireless Management Licenses

Wireless management of APs is available from the Vista Manager EX network management platform, and from the wireless controller in the Device GUI on the switch and firewall products listed in the following table.

Platform	License Name	Description	Max Supported APs
Vista Manager EX	AT-FL-VISTA-BASE-1/5YR	Vista Manager EX network monitoring and management software license	NA
Vista Manager EX (Virtual (VRT))	AT-FL-VISTA-AWC10-1/5YR⁽²⁾	Vista Manager AWC plug-in license for managing up to 10 access points	3000
Vista Manager EX (Network Appliance)	AT-FL-VISTA-AWC10-1/5YR⁽²⁾	Vista Manager AWC plug-in license for managing up to 10 access points	500
SwitchBlade x908 GEN2	AT-SW-AWC10-1/5YR⁽³⁾	Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points	305
x950 Series	AT-SW-AWC10-1/5YR⁽³⁾	Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points	185
x930 Series	AT-SW-AWC10-1/5YR⁽³⁾	Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points	125
x550 Series	AT-SW-AWC10-1/5YR⁽³⁾	Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points	45
x540L Series	AT-SW-AWC10-1/5YR⁽³⁾	Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points	45
x530 Series	AT-SW-AWC10-1/5YR⁽³⁾	Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points	45
ARX200S-GTX	AT-RT-AWC10-1/5YR⁽⁴⁾	Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points	50
AR4050S UTM Firewall	AT-RT-AWC5-1/5YR⁽³⁾	Cumulative Autonomous Wave Controller (AWC) license for up to 5 access points	25

⁽²⁾ The AWC plug-in requires an AWC license, and a Vista Manager EX base license to operate on Vista Manager EX

⁽³⁾ 5 APs can be managed for free. Purchase one license per 10 additional APs on switches, or one license per 5 additional APs on the AR4050S Firewall

⁽⁴⁾ 20 APs can be managed for free on the ARX200S-GTX, and an additional 30 APs with a license.
