The IE560-12GSX Industrial Ethernet distribution switch provides secure data transfer to support critical infrastructure in harsh environments such as power utility, industrial automation, oil and gas, transportation, and more. The ability to stack four units provides a resilient distribution solution, while MACsec encryption and Active Fiber Monitoring ensure secure and efficient infrastructure operation.
Overview
- Bridge the gap between the access layer and the core network, handling traffic aggregation and policy enforcement
- Centralized management, visibility, and automation of the entire network using Vista Managerâ„¢ and Autonomous Management Frameworkâ„¢ Plus
- Enable resilient network without single points of failure combining virtual stacking (VCStack) with either link aggregation (LAG) or ring protection switching technologies (ERPS and EPSR)
- Enjoy flexible deployment options with 8 x 100/1000X SFP ports, and 4 x 1/10G SFP+ ports
- Ensure smooth transportation, marine, and mining operation with live signalling, preventative risk management, and increased safety
- Hardened industrial-grade switch that operates flawlessly in harsh environments, withstanding electromagnetic noise, wide temperature, humidity, vibration, and more
- Optimize utility, power, and critical infrastructure operation with seamless access to control systems, process data, and monitoring
- Secure essential services infrastructure and data against sniffing or exploitation with MACsec encryption on all ports
Key Features
- 1GbE fiber LAN ports with 100M/1/10GbE fiber uplinks
- Active Fiber Monitoringâ„¢ (AFM) detects and prevents tampering of fiber uplinks
- Alarm monitoring and triggers for proactive administration
- AlliedWare Plusâ„¢ feature-rich operating system
- Electromagnetic compatibility for use in power substations
- Extended operating temperature of -40°C to 75°C for harsh environments
- Fanless design for increased reliability and dust resistance
- MACsec encryption @256bits on any port
- MODBUS/TCP for industrial automation and supervision
- MRP, EPSRingâ„¢, and G.8032 ERPS for resilient distribution rings
- NETCONF/RESTCONF and OpenFlow v1.3 for network automation and orchestration
- Precise time synchronization (IEEE 1588 PTP – Transparent Clock)
- Redundant power inputs maximize uptime and resiliency
- Static and dynamic routing (ECMP, OSPF, RIP, Static and BGP)
- Virtual Chassis Stacking (VCStackâ„¢) up to 4 units
Specifications
| Product | 100M/1000X SFP Ports | 1/10 Gigabit SFP+ Ports | Total Ports | Switching Fabric | Forwarding Rate |
|---|---|---|---|---|---|
| IE560-12GSX | 8 w/ MACsec | 4 w/ MACsec | 12 | 96Gbps | 71.4Mpps |
Physical
| Product | Width x Depth x Height | Weight | Enclosure | Mounting | Protection Rate |
|---|---|---|---|---|---|
| IE560-12GSX | 91 x 158 x 153 mm (3.58 x 6.23 x 6.027 in) |
DIN rail: 2.2 kg (4.88 lbs) Wall mount: 2.1 kg (4.64 lbs) |
Aluminum/Stainless Steel Sheet Metal shell | DIN rail, wall mount | IP30 |
Power Characteristics
| Product | Input Voltage | Cooling | Max Power Consumption | Max Heat Dissipation | Noise |
|---|---|---|---|---|---|
| IE560-12GSX | 18~57V DC | Fanless | 30W | 108.2 BTU/h | Fanless |
Latency (microseconds)
| Product | 100Mbps Port Speed | 1Gbps Port Speed | 10Gbps Port Speed |
|---|---|---|---|
| IE560-12GSX | 14.61µs | 4.58µs | 1.78µs |
Ordering Information
AT-IE560-12GSX-xx
8x 100/1000X SFP, 4x 1G/10G SFP+
Industrial Ethernet, Stackable Layer 3 Switch
Power Supplies
AT-IE048-120-20
120W @48Vdc, Industrial AC/DC power supply,
DIN rail mount (5 years warranty)
AT-SDR120-48
120W @48Vdc, Industrial AC/DC power supply,
DIN rail mount
Feature Licenses
| Name | Description | Includes |
|---|---|---|
| AT-IE560-FL01 | IE560-12GSX Premium license | BGP, BGP+ (256 routes) OSPF (256 routes) OSPFv3 (256 routes) PIM-SM, DM and SSM (256 routes) PIMv6-SM and SSM (256 routes) RIP (256 routes) RIPng (256 routes) |
All Models
Accessories
VT-Kit3
Management cable (USB to Serial Console)
SP10BD10/I
10G (LC) single-mode BiDi, I-Temp, 10km
SP10BD20
10G (LC) single-mode BiDi, 20km
SP10BD40/I
10G (LC) single-mode BiDi, I-Temp, 40km
SP10BD80/I
10G (LC) single-mode BiDi, I-Temp, 80km
SP10ER40a/I
10G (LC) single-mode, I-Temp, 40km
SP10LRa/I
10G (LC) single-mode SFP+, 10km, with Industrial Temperature rating.
SP10SR
10G (LC), multi-mode, 300m
SP10SR/I
10G (LC), multi-mode, I-Temp, 300m
SP10TM
10/100/1G/2.5G/5G/10G, 30m/100m
SP10ZR80/I
10G (LC) single-mode, 80km
SPBD10
1000LX (LC) single-mode BiDi, 10km
